PHILIPS BDL4620QL Q-Line - 46" LED-BACKLIT LCD DISPLAY EDGE LIT NO STAND

Picture/Display

Diagonal screen size (metric)

116.8  cm

Diagonal screen size (inch)

46  inch

Panel resolution

1920 x 1080p

Optimum resolution

1920 x 1080 @ 60 Hz

Brightness

350  cd/m²

Contrast ratio (typical)

4000:1

Response time (typical)

8  ms

Aspect ratio

16:9

Viewing angle (horizontal)

178  degree

Viewing angle (vertical)

178  degree

Pixel pitch

0.18 x 0.53 mm

Display colours

16.7 Million

Surface treatment

Anti-Glare coating

Picture enhancement

• 3/2 - 2/2 motion pull down
• 3D Combfilter
• Motion compens. deinterlacing
• Progressive scan
• 3D MA deinterlacing
• Dynamic contrast enhancement

Computer formats

• 640 x 480, 60, 67, 72, 75 Hz
• 800 x 600, 56, 60, 72, 75 Hz
• 1024 x 768, 60 Hz
• 1280 x 768, 60 Hz
• 1280 x 800, 60 Hz
• 1360 x 768, 60 Hz
• 1366 x 768, 60 Hz
• 1440 x 900, 60 Hz
• 1600 x 1200, 60 Hz
• 1920 x 1080, 60 Hz
• 1920 x 1200, 60 Hz

Video formats

• 480i, 60 Hz
• 480p, 60 Hz
• 576p, 50 Hz
• 576i, 50 Hz
• 720p, 50, 60 Hz
• 1080i, 50, 60 Hz
• 1080p, 50, 60 Hz

Connectivity

Video input

• DVI-D
• HDMI
• VGA (Analogue D-Sub)
• USB
• Component (RCA)
• Composite (RCA)

Audio input

• 3.5-mm jack
• Audio Left/Right (RCA)

Audio output

• SPDIF
• Audio Left/Right (RCA)

External control

• RJ45
• RS232C (in/out) 2.5 mm jack
• IR (in/out) 3.5 mm jack

Convenience

Screen-saving functions

Pixel Shift, Low Brightness

Keyboard control

Hidden

Network controllable

RS232

Signal Loop Through

RS232

Dimensions

Set Width

1068.0  mm

Set Height

622.5  mm

Set Depth

38.8  mm

Bezel width

22 mm

Product weight

13.7  kg

VESA Mount

400 x 400 mm

Box width

1164.0  mm

Box height

768.0  mm

Box depth

148.0  mm

Weight incl. Packaging

17.2  kg

Operating conditions

Temperature range (operation)

0 ~ 40  °C

Temperature range (storage)

-20 ~ 60  °C

Relative humidity

20 ~ 80  %

MTBF

50,000  hour(s)

Power

Mains power

100 ~ 240 VAC

Consumption (On mode)

60 W (EnergyStar 6.0 test method)

Standby power consumption

<0.5 W

Sound

Built-in speakers

2 x 7W RMS
